Latest Watch Battery Cross Reference Guide | Battery Chart Table 2022
Posted by SAMIR RAJ
Latest All Watch Battery Cross Reference Guide | Compatible Table - Battery Chart Guide UK 2022.
The watch battery cross reference chart is easy to use. Find the brand of your battery, then follow it down your battery model. The equivalent battery will be at the beginning of that row. Click on the blue link to go to your battery options and purchase your replacement.
Button/coin cell batteries are a group of non-rechargeable batteries. Wristwatches are commonly powered using one or rarely two-button/coin cell batteries, and these batteries have limited operating lifetime.
The list below will allow you to cross-reference your battery number to find the Renata number you will need to use on the shopping cart. Once you know the battery reference number like lr41, lr736, lr626, & lr66 etc. enter it in the search along the top of our website to quickly take you to the Silver Oxide & lithium battery details.
| Battery Cross Reference Guide | ||||||||||
| RENATA | Nom. | Dimensions | ENERGIZER | MAXELL | VARTA | RAYOVAC | DURACELL | CITIZEN | SEIKO | I.E.C. |
| No. | Capacity | (mm) | EVEREADY | PANASONIC | 60086-3 | |||||
| (mAh) | SONY | (60086-2) | ||||||||
| TOSHIBA | ||||||||||
| Silver oxide | ||||||||||
| 301 | 130 | 11.6 x 4.2 | 301 | SR43SW | V301 | 301 | D 301/386 | 280-01 | SB-A8 | SR1142 (SR43) |
| 303 | 175 | 11.6 x 5.4 | 303 | SR44SW | V303 | 303 | D 303/357 | 280-08 | SB-A9 | SR1154 (SR44) |
| 309 | 80 | 7.9 x 5.4 | 309 | SR754SW | V309 | 309 | D 309/393 | SR754 (SR48) | ||
| 315 | 23 | 7.9 x 1.6 | 315 | SR716SW | V315 | 315 | 280-56 | SB-AT | SR716 (SR67) | |
| 317 | 10.5 | 5.8 x 1.6 | 317 | SR516SW | V317 | 317 | 280-58 | SB-AR | SR516 (SR62) | |
| 319 | 21 | 5.8 x 2.7 | 319 | SR527SW | V319 | 319 | D 319 | 280-60 | SB-AE/DE | SR527 (SR64) |
| 321 | 14.5 | 6.8 x 1.6 | 321 | SR616SW | V321 | 321 | 280-73 | SB-AF/DF | SR616 (SR65) | |
| 329 | 37 | 7.9 x 3.1 | 329 | SR731SW | V329 | 329 | SR731 | |||
| 335 | 6 | 5.8 x 1.2 | 335 | SR512SW | V335 | 335 | 280-68 | SB-AB | SR512 | |
| 337 | 8 | 4.8 x 1.6 | 337 | SR416SW | 337 | SR416 | ||||
| 339 | 11 | 6.8 x 1.4 | 339 | SR614SW | V339 | SR614 | ||||
| 341 | 15 | 7.9 x 1.4 | 341 | SR714SW | V341 | 341 | SR714 | |||
| 344 | 105 | 11.6 x 3.6 | 344 | SR1136SW | V344 | 344 | SR1136 (SR42) | |||
| 346 | 9.5 | 7.9 x 1.2 | 346 | SR712SW | V346 | 346 | 280-66 | SB-DH | SR712 | |
| 350 | 105 | 11.6 x 3.6 | 350 | V350 | SR1136 (SR42) | |||||
| 357 | 160 | 11.6 x 5.4 | 357 | SR44W | V357 | 357 | D 303/357 | 280-62 | SB-B9 | SR1154 (SR44) |
| 361 | 24 | 7.9 x 2.1 | 361 | SR721W | V361 | 361 | D 361/362 | 280-53 | SB-BK/EK | SR721 (SR58) |
| 362 | 23 | 7.9 x 2.1 | 362 | SR721SW | V362 | 362 | D 361/362 | 280-29 | SB-AK/DK | SR721 (SR58) |
| 364 | 19 | 6.8 x 2.1 | 364 | SR621SW | V364 | 364 | D 364 | 280-34 | SB-AG/DG | SR621 (SR60) |
| 366 | 47 | 11.6 x 1.6 | 366 | SR1116SW | V366 | 366 | 280-46 | SR1116 | ||
| 370 | 40 | 9.5 x 2.1 | 370 | SR920W | V370 | 370 | D 370/371 | 280-51 | SB-BN | SR921 (SR69) |
| 371 | 35 | 9.5 x 2.0 | 371 | SR920SW | V371 | 371 | D 370/371 | 280-31 | SB-AN | SR921 (SR69) |
| 373 | 29 | 9.5 x 1.6 | 373 | SR916SW | V373 | 373 | 280-45 | SB-AJ/DJ | SR916 (SR68) | |
| 376 | 27 | 6.8 x 2.6 | 376 | SR626W | 376 | D 376 | MA | SR626 (SR66) | ||
| 377 | 24 | 6.8 x 2.6 | 377 | SR626SW | V377 | 377 | D 377 | 280-39 | SB-AW | SR626 (SR66) |
| 379 | 16 | 5.8 x 2.1 | 379 | SR521SW | V379 | 379 | D 379 | 280-59 | SB-AC/DC | SR521 (SR63) |
| 380 | 82 | 9.5 x 3.6 | SR936W | SR936 | ||||||
| 381 | 50 | 11.6 x 2.1 | 381 | SR1120SW | V381 | 381 | D 381/391 | 280-27 | SB-AS/DS | SR1121 (SR55) |
| 384 | 45 | 7.9 x 3.6 | 384 | SR41SW | V384 | 384 | D 384/392 | 280-18 | SB-A1/D1 | SR736 (SR41) |
| 386 | 130 | 11.6 x 4.2 | 386 | SR43W | V386 | 386 | D 301/386 | 280-41 | SB-B8 | SR1142 (SR43) |
| 389 | 80 | 11.6 x 3.1 | 389 | SR1130W | V389 | 389 | D 389/390 | 280-15 | SB-BU | SR1130 (SR54) |
| 390 | 60 | 11.6 x 3.1 | 390 | SR1130SW | V390 | 390 | D 389/390 | 280-24 | SB-AU | SR1130 (SR54) |
| 391 | 50 | 11.6 x 2.1 | 391 | SR1120W | V391 | 391 | D 381/391 | 280-30 | SB-BS/ES | SR1121 (SR55) |
| 392 | 45 | 7.9 x 3.6 | 392 | SR41W | V392 | 392 | D 384/392 | 280-13 | SB-B1 | SR736 (SR41) |
| 393 | 80 | 7.9 x 5.4 | 393 | SR754W | V393 | 393 | D 309/393 | SB-B3 | SR754 (SR48) | |
| 394 | 80 | 9.5 x 3.6 | 394 | SR936SW | V394 | 394 | D 394 | 280-17 | SB-A4 | SR936 |
| 395 | 55 | 9.5 x 2.7 | 395 | SR927SW | V395 | 395 | D 395/399 | 280-48 | SB-AP/DP | SR927 (SR57) |
| 396 | 32 | 7.9 x 2.6 | 396 | SR726W | V396 | 396 | D 396/397 | 280-52 | SB-BL | SR726 (SR59) |
| 397 | 32 | 7.9 x 2.6 | 397 | SR726SW | V397 | 397 | D 396/397 | 280-28 | SB-AL | SR726 (SR59) |
| 399 | 53 | 9.5 x 2.7 | 399 | SR927W | V399 | 399 | D 395/399 | 280-44 | SB-BP/EP | SR927 (SR57) |
| Alkaline | ||||||||||
| LR44 | 110 | 11.6 x 5.4 | A76 | LR44 | V13GA | RW82 | LR44 | 280-904 | SB-F9 | LR1154 (LR44) |
| Lithium | ||||||||||
| CR1025 | 30 | 10.0 x 2.5 | CR1025 | CR1025 | CR1025 | |||||
| CR1216 | 30 | 12.5 x 1.6 | CR/BR1216 | CR/BR1216 | CR1216 | BR1216 | CR1216 | |||
| CR1220 | 40 | 12.5 x 2.0 | CR1220 | CR/BR1220 | CR1220 | CR1220 | DL1220 | SB-T13 | CR1220 | |
| CR1225 | 48 | 12.5 x 2.5 | CR/BR1225 | BR1225 | BR1225 | BR1225 | ||||
| CR1616 | 50 | 16.0 x 1.6 | CR/BR1616 | CR/BR1616 | CR1616 | BR1616 | DL1616 | 280-209 | CR1616 | |
| CR1620 | 68 | 16.0 x 2.0 | CR1620 | CR1620 | CR1620 | CR1620 | DL1620 | 280-208 | CR1620 | |
| CR1632 | 137 | 16.0 x 3.2 | CR1632 | |||||||
| CR2016 | 90 | 20.0 x 1.6 | CR/BR2016 | CR/BR2016 | CR2016 | CR/BR2016 | DL2016 | 280-202/4/6 | SB-T11 | CR/BR2016 |
| CR2025 | 165 | 20.0 x 2.5 | CR2025 | CR2025 | CR2025 | CR2025 | DL2025 | 280-205 | SB-T14 | CR2025 |
| CR2032 | 225 | 20.0 x 3.2 | CR/BR2032 | CR/BR2032 | CR2032 | CR2032 | DL2032 | SB-T15 | CR2032 | |
| CR2320 | 150 | 23.0 x 2.0 | BR2320 | CR/BR2320 | CR2320 | BR2320 | 280-201 | CR/BR2320 | ||
| CR2325 | 190 | 23.0 x 2.5 | BR2325 | BR2325 | BR2325 | SB-T12 | BR2325 | |||
| CR2430 | 285 | 24.5 x 3.0 | CR2430 | CR2430 | CR2430 | CR2430 | DL2430 | CR2430 | ||
| CR2450N | CR2450 | CR2450 | CR2450 | DL2450 | CR2450 | |||||
| Zinc | ||||||||||
| ZA 10 | 10A | DA 10 | AC230E/EZ | AC230 | PR230H | ZA10 | PR70 | |||
| ZA 312 | 312A | DA 312 | AC312E/EZ | AC312 | PR312H | ZA312 | PR41 | |||
| ZA 13 | 13A | DA 13 | AC13E/EZ | AC13 | PR13H | ZA13 | PR48 | |||
| ZA 675 | 675A | DA 675 | AC675E/EZ | AC675 | PR675H | ZA675 | PR44 | |||
Watch battery cross reference chart pdf
RENATA Cross Reference Guide
ENERGIZER Cross Reference Guide
RAYOVAC Cross Reference Guide
PANASONIC Cross Reference Guide
VARTA Cross Reference Guide
